Commodity name: MQ1350B Cylindrical grinder 3000mm
Commodity ID: MQ1350B

▌Introduction

MQ1350B series cylindrical grinder is suitable for grinding the cylindrical or conical rotary workpiece with IT6~IT7 accuracy, and is used for single piece small batch production. This series of machine tools have distances of 1000, 1500, 2000, 3000, 4000 ㎜ in different lengths, which can be selected by users according to their needs. Structural features: a. The longitudinal movement of the machine tool workbench can be driven by hydraulic stepless speed change or by hand wheel. b. The cross feed of the grinding wheel holder is made by hydraulic pressure for micro automatic periodic feed and fast advance/retreat, and the coarse and fine feed can also be realized by hand wheel.

▌Characteristic
MQ1350B cylindrical grinder is suitable for grinding the cylindrical or conical rotary workpiece with IT6~IT7 accuracy, and is used for single piece small batch production. This series of machine tools have distances of 1000, 1500, 2000, 3000, 4000 ㎜ in different lengths, which can be selected by users according to their needs. Structural features: a. The longitudinal movement of the machine tool workbench can be driven by hydraulic stepless speed change or by hand wheel. b. The cross feed of the grinding wheel holder is made by hydraulic pressure for micro automatic periodic feed and fast advance/retreat, and the coarse and fine feed can also be realized by hand wheel. c. The workpiece, grinding wheel, oil pump and cooling pump are driven by separate motors.

▌Parameter

Parameter	Unit	MQ1350B
Grinding diameter	mm	Φ25~φ500
Max.grinding length	mm	1000/1500/2000/3000/4000
Max.workpiece weight	kg	2000
Center height	mm	270
Wheel size	mm	Φ75075305
Wheel peripheral velocity	m/s	35
